    1 pcs : FFC2B28-04-G - CONN FFC FPC 4POS 0.5MM R/A
    • 1 pcs : FFC2B28-04-G - CONN FFC FPC 4POS 0.5MM R/A

    1 pcs : FFC2B28-04-G - CONN FFC FPC 4POS 0.5MM R/A

    1Allparts2073FFC2B2804GTRND
    GCT
    £8.64
    Delivery: 10-15 business days
    Quantity
    Last items in stock
    3 Items

    Description
    4 Position FFC, FPC Connector Contacts, Top and Bottom 0.020' (0.50mm) Surface Mount, Right Angle
    Product Details
    GCT
    1Allparts2073FFC2B2804GTRND
    FFC2B28-04-G
    3 Items

    Data sheet

    Manufacturer
    GCT
    Operating temperature
    -25°C ~ 85°C
    Part status
    Active
    Contact material
    copper alloy
    Number of positions
    4
    Series
    FFC2B28
    Voltage Rating
    30V
    Mounting Type
    Surface Mount, Right Angle
    Housing Material
    Thermoplastic
    Termination
    Solder
    Features
    Solder Retention
    Pitch
    0.020' (0.50mm)
    Actuator Material
    Thermoplastic
    Packaging
    Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
    Base Product Number
    FFC2B28
    Current Rating (Amps)
    0.2A
    Contact Finish
    Gold
    Contact Finish Thickness
    Flash
    Flat Flex Type
    FFC, FPC
    Connector/Contact Type
    Contacts, Top and Bottom
    FFC, FCB Thickness
    0.30mm
    Height Above Board
    0.039' (1.00mm)
    Locking Feature
    Flip Lock, Backlock
    Cable End Type
    Tapered
    Material Flammability Rating
    UL94 V-0
    Housing Color
    Natural
    Actuator Color
    Black
    Mating Cycles
    20
