    50 pcs - 08FLT-SM2-TB(LF)(SN) JST 0.5mm Pitch 8 Way Straight Female FPC Connector, ZIF Vertical Contact
    • 50 pcs - 08FLT-SM2-TB(LF)(SN) JST 0.5mm Pitch 8 Way Straight Female FPC Connector, ZIF Vertical Contact

    50 pcs - 08FLT-SM2-TB(LF)(SN) JST 0.5mm Pitch 8 Way Straight Female FPC Connector, ZIF Vertical Contact

    50(Allparts)6386287
    JST
    50 pcs - 08FLT-SM2-TB(LF)(SN) JST 0.5mm Pitch 8 Way Straight Female FPC Connector, ZIF Vertical Contact
    £64.47
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    JST FLT series 0.5mm FPC ConnectorsThe FLT range of FPC connectors from JST are designed for use with 0.5mm pitch FPC and membrane switch leads. These top entry SMT-mounting connectors are made from heat resistant plastic to allow for reflow soldering. They feature low insertion force and have staggered surface mount tails.Features & Benefits• Voltage rating: 50V ac/dc• Current rating: 0.5A• Initial contact resistance: <, 50mΩ• Low insertion force• Staggered SMT tails on 1.0mm pitch• UL Recognized E60389• CSA Certified LR20812• RoHS Compliant0.5mm FFC/FPC Connectors, JST
    Product Details
    JST
    50(Allparts)6386287
    08FLT-SM2-TB(LF)(SN)
    10 Items

    Data sheet

    Manufacturer
    JST
    Current rating
    500mA
    Contact material
    phosphor bronze
    Contact plating
    Tin over Copper
    A-Supplier
    Allparts-UK/15/R-10
    Voltage Rating
    50 V ac/dc
    Maximum Operating Temperature
    +85°C
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -25°C
    Housing Material
    Nylon
    Number of Contacts
    8
    Termination Type
    ZIF Vertical Contact
    Gender
    Female
    Termination Method
    Solder
    Body Orientation
    Straight
    Number of Rows
    1
