    50 pcs - 22FMZ-BT (LF)(SN) JST 1mm Pitch 22 Way Straight Female FPC Connector
    • 50 pcs - 22FMZ-BT (LF)(SN) JST 1mm Pitch 22 Way Straight Female FPC Connector

    50 pcs - 22FMZ-BT (LF)(SN) JST 1mm Pitch 22 Way Straight Female FPC Connector

    50(Allparts)6388902
    JST
    50 pcs - 22FMZ-BT (LF)(SN) JST 1mm Pitch 22 Way Straight Female FPC Connector
    £61.48
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    JST FMZ series 1.0mm FFC ConnectorsThe FMZ range of ZIF (zero insertion force) FFC connectors from JST was developed to increase wear resistance and extend the mating life of the connectors. They feature a double-leaf contact construction which provides a stable connection and enhances reliability. Both top and side entry versions are available, with from 6 to 30 ways.• Voltage rating: 50V ac/dc• Current rating: 0.5A• Initial contact resistance: <, 20mΩ• Zero insertion force mechanism• Double leaf contacts• UL Recognized E60389• CSA Certified LR20812• RoHS Compliant1.0mm FFC/FPC Connectors, JST
    Product Details
    JST
    50(Allparts)6388902
    22FMZ-BT (LF)(SN)
    10 Items

    Data sheet

    Manufacturer
    JST
    Current rating
    500mA
    Contact material
    phosphor bronze
    Contact plating
    Tin over Copper
    A-Supplier
    Allparts-UK/15/R-10
    Voltage Rating
    50 V ac/dc
    Maximum Operating Temperature
    +85°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -25°C
    Housing Material
    PBT
    Number of Contacts
    22
    Gender
    Female
    Termination Method
    Solder
    Body Orientation
    Straight
