Flat face quick connector 1 2 a13 m stucchi

ORIGINAL ITALIAN Flat-Face dry shut-off quick connector Thread 1/2' A13 M. plugPressure 330 bar !!!- Interchange ISO 16028

- Type Flat Face

- Connection under pressure not allowed

- Material / Processing Carbon steel, Cr3

- Push connection system

- Nitrile NBR seal

- operating pressure Plug up to 330 bar

- Ball locking mechanism, safety lock

A series flat-face dry disconnect quick connectors are a special type of connectors that are characterized by a unique internal design combined with a durable material. Thanks to this connection, it is possible to achieve a higher working pressure and a minimum pressure drop.

This series of dry break quick connectors are designed in a modular design that allows offering different thread types or special ports. Thanks to this, you can adapt the connector to various applications while maintaining compact dimensions.

Flat-face quick connectors from the A series are particularly popular in hydraulic systems, where it is important to achieve high efficiency and eliminate contamination and fluid loss in the system. Thanks to the special internal structure and durable material, these connectors are able to meet the requirements of high pressure and minimal pressure drop, which translates into the efficiency and reliability of the hydraulic system.

It is worth noting that the A series flat-face dry disconnect connectors are specially adapted to working in difficult conditions where exceptional pressure retention and minimal fluid loss are required. Thanks to them, it is possible to construct hydraulic systems with high efficiency and reliability, while ensuring protection against contamination, which is important for maintaining the longevity and proper operation of the system.

We also offer quick connectors in other dimensions and types.
