Description
Uncoated Ferrite Core Toroid Type Length Width 0.374' (9.50mm) Diameter 0.125' (3.18mm) Height
Product Details
1AllpartsUK19341508ND
5980000201
3 Items
Data sheet
- Manufacturer
- Fair-Rite Products Corp.
- Tolerance
- ±25%
- Part status
- Active
- Diameter
- 0.374' (9.50mm)
- Width
- -
- Height
- 0.125' (3.18mm)
- Length
- -
- Series
- HF
- Finish
- Uncoated
- Core Type
- Toroid
- Packaging
- Bulk
- Supplier Device Package
- -
- Gap
- Ungapped
- Inductance Factor (Al)
- 245 nH
- Effective Length (le) mm
- 20.7
- Effective Area (Ae) mm²
- 7.3
- Core Factor (ΣI/A) mm⁻¹
- 286
- Effective Magnetic Volume (Ve) mm³
- 150
- Initial Permeability (µi)
- 550
