Toothed V-belt Avx 13 1285 mm

AVX 13 toothed V-belt, 1285 mm

Part number: K.AVX131285

EAN: 4014486110357

Unit: Art

Specifications: Extremely high abrasion resistance Application: Engines of passenger and company vehicles Features: Quiet operation Technical information:

Split length = external length - 18 mm

Internal length = external length - 63 mm

Benefits: Maintenance-free Profile: AVX13

Base length: 1267mm

Width: 13mm

Bottom width: 9.6mm

Height: 10mm

Internal length: 1222mm External length: 1285mm

Material: Rubber

Core material: Polyester

Operating temperature min.: -40°C

Operating temperature max.: 120°C

Min. pulley diameter: 80mm Number of sections {grooves}: 1

Punched: No

Small length tolerance: Yes

Toothed: Yes

To the tensioner: No

Oil resistance: Yes

Discharge of electrical charges: No

With additional outer layer: No

Quantity in package: 1 pc.

The product fits the machines:

DEUTZ-FAHR Series Agrocompact 3.xx Agrocompact 70F3 (20') Sn. -3001, Agrocompact 70F3 (20') Sn. -3001, Agrocompact 70F3 (20') Sn. -3001

Series Agrocompact F 70F3 (20')- 3001, 70F3 (24-28 Inch), F 70 F3, F 75, 70F3 (20')- 3001, 70F3 (24-28 Inch)

Series Agroplus F Agroplus F70 Sn.- D10F673WVT2E3001, Agroplus F70 Sn.- D10F673WVT2E3001, Agroplus F70 Sn.- D10F673WVT2E6001, Agroplus F70 Sn.- D10F673WVT2E6001, Agroplus F75 Sn.- D10 F704WVT2E6001, Agroplus F75 Sn.- D10F704WVT2E6001, Agroplus F70 Sn.- D10F673WVT2E3001, Agroplus F70 Sn.- D10F673WVT2E6001, Agroplus F75 Sn.- D10F704WVT2E6001

Series Agroplus S Agroplus S70 (20'') Sn.- D10N673WVT8001, Agroplus S70 (20'') Sn.- D10N673WVT8001, Agroplus S70 (24''-28'') Sn.- D10N673WVT6001, Agroplus S70 (24''- 28 '') Sn.- D10N673WVT6001, Agroplus S75 (20 '') Sn.- D10N704WVT8001, Agroplus S75 (20 '') SN.- D10N704WVT8001, AGROPLUS S75 (24 '' '- 28' ') S75 (24''-28'') Sn.- D10N704WVT6001, Agroplus S70 (20'') Sn.- D10N673WVT8001, Agroplus S70 (24''-28'') Sn.- D10N673WVT6001, Agroplus S75 (20'') Sn.- D10N704WVT8001, Agroplus S75 (24''-28'') Sn.- D10N704WVT6001, S 100, S 70, S 75, S 90

Same Series Dorado S Dorado S 70, Dorado S 75

Hürlimann Series XF XF 70, XF 75

Series XS XS 70, XS 75

Lamborghini Series RS RS.70, RS.75

Series RV RV.70, RV.75
