Toothed V-belt Avx 13 1225 mm

AVX 13 toothed V-belt, 1225 mm

Part number: K.AVX131225

EAN: 4014486110326

Unit: Art

Specifications: Extremely high abrasion resistance Application: Engines of passenger and company vehicles Features: Quiet operation Technical information:

Split length = external length - 18 mm

Internal length = external length - 63 mm

Benefits: Maintenance-free Profile: AVX13

Base length: 1207mm

Width: 13mm

Bottom width: 9.6mm

Height: 10mm

Internal length: 1162mm External length: 1225mm Material: Rubber

Core material: Polyester

Operating temperature min.: -40°C

Operating temperature max.: 120°C

Min. pulley diameter: 80mm Number of sections {grooves}: 1

Punched: No

Small length tolerance: Yes

Toothed: Yes

To the tensioner: No

Oil resistance: Yes

Discharge of electrical charges: No

With additional outer layer: No

Quantity in package: 1 pc.

The product fits the machines:

Fendt Series Farmer 100 FARMER 102 - Sn. 135/04601-99999, FARMER 103 - Sn. 138/11401-99999, FARMER 104 - Sn. 238/20701-99999, FARMER 105 - Sn. 258/10601-99999, FARMER 108 - Sn. 278/00001-99999, FARMER 5S/106 - Sn. 268/00001-99999, FARMER 5S/106 - Sn. 268/00001-99999, FARMER 5S/106 - Sn. 268/00001-99999, FARMER 5S/106 - Sn. 268/00001-99999, FARMER 5S/106 - Sn. 268/00001-99999

Series Farmer 200 FARMER 240S - Sn. 294/00001-99999, FARMER 250S - Sn. 295/00001-99999, FARMER 250V - Sn. 205/00001-99999, FARMER 260P - Sn. 246/00001-99999, FARMER 260S - Sn. 296/00001-99999, FARMER 260V - Sn. 206/00001-99999, FARMER 270P - Sn. 247/00001-99999, FARMER 270V - Sn. 207/00001-99999, FARMER 275S - Sn. 297/00001-07000, FARMER 275V - Sn. 208/00001-07000, FARMER 280P - Sn. 248/00001-99999, FARMER 280S - Sn. 297/07001-99999, FARMER 280V - Sn. 208/07001-99999

Same Series Dorado Dorado 55, Dorado 60, Dorado 65, Dorado 70, Dorado 75, Dorado 85

Series Dorado S Dorado S 100, Dorado S 70, Dorado S 75, Dorado S 90

Series Dorado V Dorado V 100, Dorado V 70, Dorado V 75, Dorado V 90

Schlüter Series Compact Compact 950 V6, Compact 950/TV

Series Super Super 550/V

Hürlimann Series XF XF 100, XF 70, XF 75, XF 90

Series XS XS 100, XS 70, XS 75, XS 90

Lamborghini Series RS RS.100, RS.70, RS.75, RS.90

Series RV RV.100, RV.70, RV.75, RV.90

Mercedes Benz Series MB-Trac MB-Trac 700 (OM 314), MB-Trac 800 (OM 314)

Massey Ferguson Series 154 - 194 174, 194 174, 194 174, 194 184, 194 184, 194 184, 194 194, 194 194, 194 194

Series 155 - 168 158, 168 158, 168 158
