optibelt c63 22x1600 V-belt

Optibelt V-belt, C63 22x1600

Part number: K. VB221600

EAN: 4014486037371

Unit: Art

Specifications: Abrasion-resistant outer fabric Application:

Machine construction

Construction machinery

Agricultural machinery

Gardening machinery

Features:

Optimum operational properties

Uniform force transfer

V-belts in the S=C version can be used as a set

Technical information:

Split length = inner length + 58 mm

Outer length = inner length + 88 mm

Benefits: Rare downtime

Profile: C/22

Base length: 1658mm

Width: 22mm

Bottom width: 12.3mm Height: 14mm

Internal length: 1600mm External length: 1688mm

Material: Rubber

Core material: Polyester

Operating temperature min.: -40°C

Operating temperature max.: 70°C

Min. pulley diameter: 180mm Number of sections {grooves}: 1

Punched: No

Small length tolerance: Yes

Teething: No

To the tensioner: No

Oil resistance: Yes

Discharge of electrical charges: No

With additional outer layer: Yes

Quantity in package: 1 pc.
