Special wire with triple insulation trw b 0 55

Special triple-insulated wire TRW-B-0.55, yellow. The purchase of 1 piece of the item is the purchase of 1 meter of triple-insulated wire with a bare copper diameter of 0.55 mm

The color of the insulation coating - sent randomly - it is usually YELLOW

Wire covered with ETFE insulation - wall thickness 0.10 mm with the following parameters:

Long-term operating temperature of 150 °C

Excellent resistance to low temperatures, ability to work up to -80 °C

Very good resistance to weather conditions

Very good chemical resistance

Very good radiation resistance high energy

Hydrolytic stability

Good impact resistance

The offered wire can be successfully used in demanding applications where other materials have insufficient mechanical, temperature or chemical resistance. The material meets fire protection requirements in accordance with the UL94-V0 standard and ensures low smoke emissions during combustion.

When purchasing several pieces, the wire will be delivered in one piece. The purchased wires are wound on special spools, protecting the copper against damage during transport.
