    1 pcs - Wago 859 Series Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 5A Load
    • 1 pcs - Wago 859 Series Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 5A Load

    1 pcs - Wago 859 Series Interface Relay, DIN Rail Mount, 24V ac/dc Coil, SPDT, 5A Load

    Allparts-UK/15/R/180-3050
    WAGO
    £46.65
    Delivery: 4-7 business days
    Quantity
    14 Items

    Product Details
    WAGO
    Allparts-UK/15/R/180-3050
    859-354
    14 Items

    Data sheet

    Manufacturer
    WAGO
    Dimensions
    6 x 56 x 91mm
    Height
    56mm
    Length
    6mm
    Contact material
    silver alloy
    Depth
    91mm
    Input current
    8mA
    A-Supplier
    Allparts-UK-R
    Series
    859
    Terminal Type
    Cage Clamp
    Maximum Operating Temperature
    +50°C
    Mounting Type
    DIN Rail
    Minimum Operating Temperature
    -25°C
    Standards Met
    DNV GL TAA00001D1, EN 61010-2-201, EN 61373, EN 61810-1, GL, NK TA17255M, PRS TE/1989/880590/13, UL, UL E175199 Sec.6
    Contact Configuration
    SPDT
    Life
    5 x 10^6 (Mechanical) cycles, 50 x 10^3 (Electrical) cycles
    Special Features
    LED Indication
    Operating Temperature Range
    -25 - +50°C
    Maximum Input Voltage
    24V ac/dc
    Switching Voltage
    250V ac
    Input Voltage Range
    (Maximum) 24V ac/dc
    Relay Switching Classification
    Miniature Switching Relay
    Load Current Rating
    5A
    Load Voltage Rating
    250V ac
    Coil Voltage
    24V ac/dc
