Battery isolator charging separator 12v 125a

Battery isolator charging separator

The battery isolator charges the additional battery while the vehicle engine is running and prevents the main battery from discharging when the vehicle is stationary. The device monitors the voltage of the main battery - if it detects its increase above 13.3V, it will close the relay contacts, causing current to flow to the second battery (the LED indicator will light up). After turning off the ignition (below 12.8V), the relay will open its contacts so as not to discharge the main battery.

ATTENTION! During installation, please follow all safety rules for installation and use.

FEATURES

enables simultaneous charging of two 12-volt batteries in a vehicle, camper, etc. without having to worry about using an additional battery when stationary

voltage 12V

universal use: cars, campers, boats, etc.

charging current: 80-100A (continuous value ), 125A (temporary value)

has an LED indicating the operation of the device

switches the relay on from 13.3V up

switches the relay off at 12.8V down

current consumption by the device: STANTBY 1mA, CHARGING 250mA

time switching: 3 - 5 seconds

dimensions: 6.5cm x 5.2cm x 6.7cm

tightness class IP65

The price is for 1 pc.
