HC cargo starter 111197 12v 2 0kw

HC Cargo starter 111197 12V 2.0kWHC Cargo starter 111197 12V 2.0kW.

Electrical data

Voltage

12

kW

2.0

Dimensions

H

Number of teeth

9

P

Head. rotation

CW

N

Gear type

GR

A

Flange mounting

82.50

I

B+

M8

Number of mounting holes

2 (0)

B

Length. bendiksu

26.00

E

Mounting hole 1 mm

12.20

E

Mounting hole 2 mm

12.20

F

Distance (rear)

148.00

G

Distance (front)

38.50

M

Mounting bracket

No

O

Distance in mm

105.00

R

Total length in mm

232.50

Application:Atlas Copco, PrzemyslBobcat, PrzemyslBomag, PrzemyslCaterpillar, PrzemyslDoosan, PrzemyslHyundai, PrzemyslJohn Deere, PrzemyslKawasaki, PrzemyslKubota, PrzemyslKubota, Agricultural machineryKubota, Industrial enginesManitou, PrzemyslTerex, PrzemyslVarious Agriculture Vehicles, Agricultural machineryVolvo, Industry

Numbers comparative:

028000-9030 Denso Parts List028000-9031 Denso Parts List028000-9032 Denso Parts List15425-63010 Kubota 15425-63011 Kubota 15425-63012 Kubota Parts List15425-63 013 Kubota 15425-63014 Kubota 15425-63016 Kubota 16652 -63012 Kubota 16652-63013 Kubota 17121-63010 Kubota 17123-63016 Kubota 17490-63014 Kubota 1K371-63010 Kubota 228000-0691 Denso Parts List228000-4570 Denso Parts List22800 0-4571 Denso 228000-4572 Denso 228000-4573 Denso 228000-4590 Denso 228000 -4591 Denso 228000-4592 Denso 228000-4593 Denso 228000-4750 Denso 228000-5270 Denso 228000-5273 Denso 428000-2030 Denso

AD Kühner

20780,Autostarter Poland

S6334(DENSO),Autostarter Poland

S6096,Casco

CST40129,Casco

CST40311,Elstock

25- 5170,Elstock

25-2086,Elstock

25-2109,FARCOM

103941,Hella

8ea732665-001,Lester< p>

18154,Lester

18275,Lester

18004,Lucas

LRS01316,Lucas

LRS02572,PIC< p>

190-593,PIC

190-757,PIC

190-425,Pos Service Holland

690.539.092,Spidan< p>

4300,Wai

18004N,Wai

18154N,Wai

18411N,Wai

2-2209- ND,Wilson

91-29-5183,Wood Auto

STR30039
