Complete clutch with case ih internati bearings

The order processing time is 5 business days. Please consider your purchases carefully!

Complete clutch with bearings Case IH / International Harvester 5171137 Quality of the free disc multi-groove hole 10

Number of multi-groove holes of the captive disc 14

Dia. internal multi-groove hole of free disk, mm 22

Dia. external multi-grooved hole of the free disc, mm 25

Size of the free disc, mm 280

Clutch pressure size (mm) 280/280

Number of levers 6

Number of screws 6 x M8 x 50 (1.25)

Tariff Code 8708939000

Housing type Cast Iron

Clutch pressure type Double clutch pressure

The set includes Double clutch pressure plate - 228007717 Discs - 328018616 Flywheel bearing - 410002540 Transmission Bearing - 500028440 Gearbox bearing - 500045900

Independent double flap control

Manufacturer LUK

Captive Disc Material Organic

Free Disc Material Organic

Free Disc Type Rigid

Technical Information Clutch Pressure Size: 280/280mm Kit includes: Double clutch pressure plate - 228007717 Discs - 328018616 Flywheel bearing - 410002540 Transmission Bearing - 500028440 Gearbox bearing - 500045900

Cushion without axial cushion

SUITABLE FOR BRAND/MOD EL

Case IH / International Harvester

JX55, JX60, JX65, JX70

Fiat

446, 450, 466, 480, 500, 540, 550, 55-46, 55-56, 55-66, 55-88, 55-90, 570, 580, 600, 60-46, 60-56, 60-66, 60-76, 60-88, 60-90, 60-93, 60-94, 62-86, 640, 65-46, 65-56, 65-66, 65-88, 65-90, 65-93, 65-94, 666, 670, 680, 70- 56, 70-66, 70-76, 70-88, 70-90, 72-86, 72-93, 72-94, 780, 80-66, 80-76, 80-88, 80-90, 82- 86, 82-93, 82-94, 85-90, 88-93, 88-94

Ford / New Holland

4030, 4230, 4430, TD55D, TD60D, TD65B , TD65D

OEM PART NUMBERS

Case IH / International Harvester 5171137 , 87689657, 5092787

Fiat 5170404 , 5171137 , 5154879 , 87689657

Ford / New Holland87689657

LUK 228 0077 17, 228007717, 628 1034 10, 628103410

Article number: S.122174
