Bearing with vertical housing complete ina fag ucp213

Bearing with plummer housing complete INA/FAG UCP213

Part number UCP213 Unit piece Features - The inner bearing has an inner ring extended on both sides with 2 adjustment screws

- Greasable

Lubrication tip thread diameter M6 Housing type Pillar bearing dInner bearing diameter. 65mm aTotal length 265mm bHousing width 70mm Total height 151mm BiWidth of the inner ring of the bearing 651mm hVertical position of the shaft/shaft 762mm nPosition of the bearing balls in relation to the mounting surface 254mm Spacing of mounting holes 203mm
