Bearing with 2-hole housing complete ina fag ucf

Bearing with housing, 2-hole, complete INA/FAG UCFL204

Part number UCFL204 Unit piece Features - The inner bearing has a double-sided extended inner ring with 2 adjustment screws

- Lubricable

Housing type Oval flange Lubrication tip thread diameter M6 dInner bearing diameter. 20mm a Total length 113mm b Housing width 60mm Total height 333mm l Housing height 255mm Bi Width of the bearing inner ring 31mm Position of the bearing balls in relation to the end of the shaft/shaft 15mm i Position of the bearing balls in relation to the mounting surface 127mm Spacing of mounting holes 90mm Diameter of mounting holes 12mm Original number UCFL204-J7
