    50 pcs - ABM8G-24.000MHZ-18-D2Y-T Abracon 24MHz Crystal Unit ±20ppm SMD 4-Pin 3.2 x 2.5 x 1mm
    • 50 pcs - ABM8G-24.000MHZ-18-D2Y-T Abracon 24MHz Crystal Unit ±20ppm SMD 4-Pin 3.2 x 2.5 x 1mm

    50 pcs - ABM8G-24.000MHZ-18-D2Y-T Abracon 24MHz Crystal Unit ±20ppm SMD 4-Pin 3.2 x 2.5 x 1mm

    50(Allparts)1712708
    ABRACON
    50 pcs - ABM8G-24.000MHZ-18-D2Y-T Abracon 24MHz Crystal Unit ±20ppm SMD 4-Pin 3.2 x 2.5 x 1mm
    £51.81
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Low in height, suitable for thin equipmentGlass sealed package assures high reliability and high temperature operationTight tolerance and stability availableIR reflow capableLow cost version of ABM8 crystalHigh density applications.Modems, communication and test equipmentPMCIA, wireless applications
    Product Details
    ABRACON
    50(Allparts)1712708
    ABM8G-24.000MHZ-18-D2Y-T
    10 Items

    Data sheet

    Manufacturer
    ABRACON
    Dimensions
    3.2 x 2.5 x 1mm
    Height
    1mm
    Length
    3.2mm
    A-Supplier
    Allparts-UK/15/R-14
    Maximum Operating Temperature
    85°C
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -40°C
    Pin Count
    4
    Package Type
    SMD
    Frequency Stability
    ±30ppm
    Frequency Tolerance
    ±20ppm
    Load Capacitance
    18pF
    Standard Frequency
    24MHz
    Series Resistance
    60Ω
