10 pcs - HS15 56R J Arcol, 56Ω 15W Wire Wound Chassis Mount Resistor HS15 56R J ±5%
    • 10 pcs - HS15 56R J Arcol, 56Ω 15W Wire Wound Chassis Mount Resistor HS15 56R J ±5%

    10 pcs - HS15 56R J Arcol, 56Ω 15W Wire Wound Chassis Mount Resistor HS15 56R J ±5%

    10(Allparts)2522619
    ARCOL
    Arcol, 56Ω 15W Wire Wound Chassis Mount Resistor HS15 56R J ±5%
    £50.04
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    15W Aluminium housed wirewound power resistor, HS Series15Watt Aluminium housed power resistors which are manufactured to be compliant with the requirements of a MIL 18546, IEC 115 and are RoHS compliant.Compact size for Power ratingWinding construction maximises High Pulse CapabilityNoteTo achieve the given maximum performance rating of this power resistor, it is designed to be directly mounted on an appropriately matched heatsink and mounted using a thermal compound.
    Product Details
    ARCOL
    10(Allparts)2522619
    HS15 56R J
    10 Items

    Data sheet

    Manufacturer
    ARCOL
    Tolerance
    ±5%
    Dimensions
    11 x 36.5 x 21mm
    Overall length
    36.5mm
    Resistance
    56Ω
    A-Supplier
    Allparts-UK/15/R-16
    Series
    HS15
    Power Rating
    15W
    Overall Width
    21mm
    Overall Height
    11mm
    Technology
    Wire Wound
    Termination Style
    Axial
    Package/Case
    Aluminium Housed
    Minimum Temperature Coefficient
    -100ppm/°C
    Maximum Temperature Coefficient
    +100ppm/°C
