Drive shaft tcvj601610enc02112

Drive shaft TCVJ601610ENC02112

Part number TCVJ601610ENC02112 Unit piece Application - Feed wagon

- Slurry barrel

- Steer

- Self-loading wagon

Properties - Lubrication frequency: 8 hours

- CE marked

Technical information - Maximum deflection angle for long-term use: 25o

- Angle deflection can only be 80o

for a short time - Observe the Comer operating instructions

- Max. dynamic capacity 540 rpm: 47kW 830Nm

- Max. dynamic capacity 1000 rpm: 74kW 710Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

External profile pipe. (mm) 54 x 4 Machine connection 1 3/8' (6) Tractor connection 1 3/8' (6) Length 1610mm Internal profile pipe. (mm) 45 x 4 Cross set 180.016.228mm Max. static load capacity 830N m
