Cardan shaft standard series 50 l 1210 mm 620 nm

PTO shaft standard series 50 L-1210 mm 620 Nm PTO50T1210

Part number PTO50T1210GP Unit piece Specifications - Good price-quality ratio Benefits - Favorable alternative in the low performance range Application - Wood splitter

- Field sprayer

- Fertilizer seeders

- Fertilizer seeders

Properties - Meets all international safety requirements

- Occurs CE marking

Technical information - Max. dynamic capacity 540 rpm: 35kW 620Nm

Max. dynamic capacity 1000 rpm: 54kW 515Nm

Outside diameter . connections on the tractor side 1-3/8 inch Number of grooves on the tractor side 6 Type of connection on the tractor side Pin Outer diameter of the connection on the machine side 1-3/8 inch Number of grooves on the machine side 6 Type of connection on the machine side Retaining ring Size PTO shaft 50 Length 1210mm Power at 540 rpm 35kW Power at 1000 rpm 54kW Diameter of the cross sleeve on the tractor side 302mm Length of the cross on the tractor side 796mm Diameter of the cross sleeve on the machine side 302mm Length of the cross on the machine side 796mm
