Wal pto comer t series 460 nm l 510 comer t400510en

PTO shaft Comer T series 460 Nm L 510 Comer T400510ENC12112

Part number T400510ENC12112 Unit piece Application - Seeders

- Rudder

- Mowers

Features - Lubrication interval: 8 hours

- CE marked

Technical information - Follow the Comer operating instructions

- Max. dynamic capacity 540 rpm: 26kW 460Nm

- Max. dynamic capacity 1000 rpm: 40kW 380Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

Outer diameter of the connection on the tractor side 1-3/8 inch Number of connection grooves on the tractor side 6 Outer diameter of the connection on the machine side 1-3/8 inch Number of connection grooves on the machine side 6 Shaft size T40 Length 510mm Diameter of the cross sleeve on the tractor side 27mm Length of the cross on the side tractor 746mm Diameter of the cross arm sleeve on the machine side 27mm Length of the cross arm on the machine side 746mm Static torque max. 460N·m
