Wal pto comer t series constant velocity joint 830 n

PTO shaft Comer T series constant velocity joint 830 Nm L 1210 Comer TCVJ601210

Part number TCVJ601210 Unit piece Application - Feed wagon

- Slurry barrel

- Steer

- Self-loading wagon

Properties - Lubrication frequency: 8 hours

- CE marked

Technical information - Maximum deflection angle for long-term use: 25o

- The deflection angle may only be 80o

for a short time - Follow the Comer operating instructions

- Max. dynamic capacity 540rpm: 47kW 830Nm

- Max. dynamic capacity 1000 rpm: 74kW 710Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

Connection outside diameter tractor 1-3/8 inch Number of connection grooves on the tractor side 6 Outer diameter of the connection on the machine side 1-3/8 inch Number of connection grooves on the machine side 6 T shaft size CvJ 60 Length 1210mm Diameter of the cross sleeve on the tractor side - the longer part 302mm Diameter cross arm sleeve on the tractor side 302mm Length of the cross arm on the tractor side - longer part 1014mm Length of the cross arm on the tractor side 954mm Diameter of the cross arm sleeve on the machine side 302mm Length of the cross arm on the machine side 92mm Static torque max. 1450N·m Original number 78611210EN0020200
