Cardan shaft standard series 20 l 1210 mm 270 nm

PTO shaft standard series 20 L-1210 mm 270 Nm PTO20T1210

Part number PTO20T1210GP Unit piece Specifications - Good price-quality ratio Benefits - Favorable alternative in the low performance range Application - Wood splitter

- Field sprayer

- Fertilizer seeders

Features - Meets all international safety requirements

- CE marked

Technical information - Max. dynamic capacity 540 rpm: 15kW 265Nm

Max. dynamic capacity 1000 rpm: 23kW 220Nm

Outer diameter of the connection on the tractor side 1-3/8 inch Number connection grooves on the tractor side 6 Outer diameter of the connection on the machine side 1-3/8 inch Number of connection grooves on the machine side 6 PTO shaft size 20 Length 1210mm Power at 540 rpm 15kW Power at 1000 rpm 23kW Cross sleeve diameter on the side tractor 238mm Length of the cross on the tractor side 613mm Diameter of the cross bush on the machine side 238mm Length of the cross on the machine side 613mm
