Wide angle roller t40 cvj series l 860 mm comer tcvj

Wide angle roller series T40 CVJ L-860 mm Comer TCVJ400860

Part number TCVJ400860 Unit piece Application - Field sprayers

- Manure spreaders

- Baler

- Slurry tank

Features - Tractor side 1-3/8' (6) slide

- Machine side 1-3/8' (6) pin sliding

- Lubrication frequency: 8 hours

- CE marked

Technical information - Maximum deflection angle for long-term use: 25o

- The deflection angle may only be 80°

for a short time - Observe the Comer operating instructions

- Max. dynamic capacity 540 rpm: 26kW 460Nm

- Max. dynamic capacity 1000 rpm: 40kW 380Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

Outer diameter of the connection on the tractor side 1-3/8 inch Number of grooves connections on the tractor side 6 Type of connection on the tractor side Pin Outer diameter of the connection on the machine side 1-3/8 inch Number of grooves in the connection on the machine side 6 Type of connection on the machine side Pin Shaft size T CvJ 40 Length 860mm Diameter of the cross sleeve on the tractor side - longer part 27mm Diameter of the cross sleeve on the tractor side 27mm Length of the cross on the tractor side - longer part 912mm Length of the cross on the tractor side 858mm Diameter of the cross sleeve on the machine side 27mm Length of the cross on the machine side 746mm Static torque max. 780N·m
