Wal comer t90 series 1560 nm l 1010 mm comer t90101

Shaft Comer series T90 1560 Nm L-1010 mm Comer T901010

Part number T901010 Unit piece Application - Heavy soil cultivation machines

- Wood chippers

- Stump grinder

Features - Lubrication interval: 8 hours

- CE marked

Technical information - Follow the Comer operating instructions

- Max. dynamic capacity 540rpm: 88kW 1560Nm

- Max. dynamic capacity 1000rpm: 140kW 1340Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

Outer diameter of the connection on the tractor side 1-3/8 inch Number of grooves in the connection on the tractor side 6 Type of connection on the tractor side Pin Outer diameter of the connection on the machine side 1-3/8 inch Number of grooves in the connection on the machine side 6 Type connections on the machine side Pin Shaft size T90 Length 1010mm Diameter of the cross sleeve on the tractor side 41mm Length of the cross on the tractor side 108mm Diameter of the cross sleeve on the machine side 41mm Length of the cross on the machine side 108mm Static torque max. 1560N·m
