Double wide angle shaft t40 460 nm l 1010 mm 2x

T40 double wide angle roller 460 Nm L=1010 mm 2xCVJ Comer T401010ENC02C02

Part number T401010ENC02C02 Unit piece Application - Field sprayers

- Manure spreaders

- Baler

- Slurry tank

Features - Tractor side 1-3/8' (6) gate

- Machine side 1-3/8' (6) ) sliding pin

- Lubrication frequency: 8 hours

- CE marked

Technical information - Maximum deflection angle for long-term use: 25o

- The deflection angle may only be 80o for a short time

- Observe the Comer operating instructions

- Max. dynamic capacity 540 rpm: 26kW 460Nm

- Max. dynamic capacity 1000 rpm: 40kW 380Nm

- Values at a deflection angle of 5° and a service life of 1000 hours

Outer diameter of the connection on the tractor side 1-3/8 inch Number of connection grooves on the tractor side 6 Type of connection on the tractor side Retaining ring Outer diameter of the connection on the machine side 1-3/8 inch Number of connection grooves on the machine side 6 Type of connection on the machine side Retaining ring Shaft size T40 Length 1010mm Cross sleeve diameter on the side tractor - longer part 27mm Diameter of the cross arm sleeve on the tractor side 27mm Length of the cross arm on the tractor side - longer part 912mm Length of the cross arm on the tractor side 858mm Diameter of the cross arm sleeve on the machine side - longer part 27mm Diameter of the cross arm sleeve on the machine side 27mm Length of the cross arm on the machine side - longer part 912mm Length of the cross on the machine side 858mm
