10 pcs - EEHAZT1J560B Panasonic 56μF Hybrid Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole - EEHAZT1J560B
    • 10 pcs - EEHAZT1J560B Panasonic 56μF Hybrid Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole - EEHAZT1J560B

    10 pcs - EEHAZT1J560B Panasonic 56μF Hybrid Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole - EEHAZT1J560B

    10(Allparts)2105780
    PANASONIC
    10 pcs - EEHAZT1J560B Panasonic 56μF Hybrid Aluminium Electrolytic Capacitor 63V dc, Radial, Through Hole - EEHAZT1J560B
    £49.95
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The Panasonic ZT series conductive polymer hybrid aluminium electrolytic capacitor has ±20 % tolerance and used 63 V voltage. It has 56μF of capacitance which size code is G and has and ultra low ESR between 16 mΩ and 32 mΩ.Endurance 4000 h at 125 ℃ (High ripple current)Taping products for automatic insertionAEC-Q200 compliant
    Product Details
    PANASONIC
    10(Allparts)2105780
    EEHAZT1J560B
    10 Items

    Data sheet

    Manufacturer
    PANASONIC
    Capacitance
    56µF
    Tolerance
    ±20%
    Dimensions
    10 (Dia.) x 9.5 x 0.6mm
    Diameter
    10mm
    Length
    9.5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    ZT-A
    Maximum Operating Temperature
    +125°C
    Mounting Type
    Radial, Through Hole
    Voltage
    63V dc
    Technology
    Hybrid
    Polarised
    Polar
    Lead Pitch
    5mm
    Automotive Standard
    AEC-Q200
