50 pcs - RS PRO 470μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole
    • 50 pcs - RS PRO 470μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole

    50 pcs - RS PRO 470μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole

    50(Allparts)1815441
    RS PRO
    50 pcs - RS PRO 470μF Aluminium Electrolytic Capacitor 50V dc, Radial, Through Hole
    £64.60
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    RS PRO Electrolytic CapacitorThe RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 470μF, at a rated voltage of 50VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.Features and Benefits• Diameter is 10mm• Dissipation factor is 10%• Height is 20mm• Lead pitch is 5mm• Leakage current is 3μA• Operating temperature ranging between -40°C and 105°C• Ripple current is 1.2A• Working voltage is 50VDCApplications• Computer peripheral• Mother boardCertifications• ANSI/ESD S20.20:2014• BS EN 61340-5-1:2007
    Product Details
    RS PRO
    50(Allparts)1815441
    10 Items

    Data sheet

    Manufacturer
    RS PRO
    Capacitance
    470µF
    Tolerance
    ±20%
    Dimensions
    10 (Dia.) x 20mm
    Leakage current
    3 μA
    Diameter
    10mm
    Height
    20mm
    A-Supplier
    Allparts-UK/15/R-10
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Radial, Through Hole
    Minimum Operating Temperature
    -40°C
    Voltage
    50V dc
    Technology
    Aluminium Electrolytic
    Lifetime
    1000h
    Ripple Current
    1.2A
    Lead Pitch
    5mm
    Dissipation Factor
    10%
