20 pcs - UCS2W100MHD Nichicon 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole - UCS2W100MHD
    • 20 pcs - UCS2W100MHD Nichicon 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole - UCS2W100MHD

    20 pcs - UCS2W100MHD Nichicon 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole - UCS2W100MHD

    20(Allparts)7152319
    NICHICON
    20 pcs - UCS2W100MHD Nichicon 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole - UCS2W100MHD
    £50.56
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Nichicon CS Series High ReliabilityNichicon CS Series Aluminium Electrolytic Capacitors are high reliability, miniature size products that have a 10,000 hour load life. The CS series features a wide temperature range, a rated voltage range of 200 to 450V, and high ripple current.High reliabilityHigh ripple currentLong life up to 10,000 hoursLead free reflow soldering
    Product Details
    NICHICON
    20(Allparts)7152319
    UCS2W100MHD
    10 Items

    Data sheet

    Manufacturer
    NICHICON
    Capacitance
    10µF
    Tolerance
    ±20%
    Dimensions
    12.5 (Dia.) x 20mm
    Diameter
    12.5mm
    Height
    20mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    CS
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Radial, Through Hole
    Minimum Operating Temperature
    -25°C
    Voltage
    450V dc
    Technology
    Aluminium Electrolytic
    Lifetime
    10000h
    Ripple Current
    450mA
    Lead Pitch
    5mm
