50 pcs - RS PRO 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole
    • 50 pcs - RS PRO 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole

    50 pcs - RS PRO 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole

    50(Allparts)1815482
    RS PRO
    50 pcs - RS PRO 10μF Aluminium Electrolytic Capacitor 450V dc, Radial, Through Hole
    £58.17
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    RS PRO Electrolytic CapacitorThe RS PRO 10μF through-hole mount electrolytic capacitor has a voltage rating of 450VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 10mm x 20mm (diameter x length). This capacitor is designed with a safety vent construction.Features and Benefits• Tolerance: ±20%• Lifetime: 1000 hours• Ripple current: 120mA• Dissipation factor: 12%• Lead pitch: 5mm• Load life: 3000∼10000 hours at 150 °C• Impedance: 4ohm• Operating temperature ranging between -25°C and 105°CApplications• Used in communication equipment• Switching power supply• Industrial measuring instrumentsCertifications• ANSI/ESD S20.20:2014• BS EN 61340-5-1:2007
    Product Details
    RS PRO
    50(Allparts)1815482
    10 Items

    Data sheet

    Manufacturer
    RS PRO
    Capacitance
    10µF
    Tolerance
    ±20%
    Dimensions
    10 (Dia.) x 20mm
    Leakage current
    3 μA
    Diameter
    10mm
    Height
    20mm
    A-Supplier
    Allparts-UK/15/R-10
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Radial, Through Hole
    Minimum Operating Temperature
    -25°C
    Voltage
    450V dc
    Technology
    Aluminium Electrolytic
    Lifetime
    1000h
    Ripple Current
    120mA
    Lead Pitch
    5mm
    Dissipation Factor
    17%
