10 pcs - RL80J102MDN1KX Nichicon 1000μF Polymer Capacitor 6.3V dc, Through Hole - RL80J102MDN1KX
    • 10 pcs - RL80J102MDN1KX Nichicon 1000μF Polymer Capacitor 6.3V dc, Through Hole - RL80J102MDN1KX

    10 pcs - RL80J102MDN1KX Nichicon 1000μF Polymer Capacitor 6.3V dc, Through Hole - RL80J102MDN1KX

    10(electronicparts)8513841
    NICHICON
    10 pcs - RL80J102MDN1KX Nichicon 1000μF Polymer Capacitor 6.3V dc, Through Hole - RL80J102MDN1KX
    £30.80
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Nichicon L8 SeriesNichicon L8 Series Functional Polymer Aluminium Electrolytic Capacitors (FPCAPs) use a functional polymer cathode that greatly improves frequency and temperature characteristics. FPCAP series capacitors offer higher performance (low resistance), greater reliability, large capacitance, high ripple current capability, and the reduction of high frequency noise. The L8 Series offer ultra-low ESR and large capacitance range.Low ESR at a high frequency rangeHigh ripple current capabilityLong life and high reliabilitySolid Radial 105°C
    Product Details
    NICHICON
    10(electronicparts)8513841
    RL80J102MDN1KX
    10 Items

    Data sheet

    Manufacturer
    NICHICON
    Capacitance
    1000µF
    Tolerance
    ±20%
    Dimensions
    8 x 8mm
    Leakage current
    1260 μA
    Diameter
    8mm
    Height
    8mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    L8
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    6.3V dc
    Technology
    Polymer
    Lifetime
    2000h
    Equivalent Series Resistance
    9mΩ
    Ripple Current
    5700mArms
    Lead Pitch
    3.5mm
